5476 tenter setting machine

The newly developed M5476 type tenter setting machine highlights the ease of operation and environmental protection and energy saving of tenter setting machine. The use of high-sealing oven technology is more conducive to energy saving and environmental protection, and the use of advanced electrical control technology highlights the ease of operation of the equipment and the stable reliability of operation.

This machine adopts a floor-standing welding rack drying room, which is convenient for manual entry into the drying room for equipment maintenance. The air spray duct can be pulled out of the drying room for cleaning in a single piece. The drying room adopts a structure of 1.5m per section and 3m per section, which is convenient for the overall combination of the rack, heat insulation board, air spray duct, circulating fan, and heating device. The temperature control accuracy is high, and the temperature on the left, center, and right of the drying room is uniform and consistent.

The main chain is driven independently, and the AC variable frequency motor and reducer are used through high-precision electrical control to ensure that the speed of the left and right chains is accurately synchronized and the maintenance workload is reduced.

Pressure sensor sampling for liquid level control of rolling mill, PLC control, touch screen setting, display liquid level height.
